The Introduction of 6101 Aluminum Sheet Plate

6101 aluminum sheet is a popular alloy that can be found in many commercial and industrial applications. It has high electrical conductivity and good mechanical strength, can be machined, welded and formed using standard methods, and it is easy to extrude. 6101 Aluminum plate can be used for high-strength conductive materials. 55% IACS guarantee, good corrosion resistance and weldability, used for processing high-strength bus conductors. 6101 is similar to 6063 aluminum sheet, but the chemical change is small, which can enhance the conductivity. Although the conductivity is slightly lower than alloy 1350, it provides greater strength.Click to Order

The Product Specification of 6101 Aluminum Sheet Plate

Alloy	6101 aluminum sheet plate
Temper	F,O, T4,T6,T651,H112,etc.
Thickness (mm)	0.30-500
Width (mm)	100-2650
Length (mm)	500-16000
Application	High-strength aluminum materials for buses, electrical conductors and radiators, busbar conductors, etc.

Chemical composition:

Alloy	Si	Fe	Cu	Mn	Mg	Zn	B	Cr	Al
6101	0.30-0.7	0.50	0.10	0.03	0.35-0.8	0.10	0.06	0.03	Remainder

The Product Features of 6101 Aluminum Sheet Plate

6101 Aluminum plat has good corrosion resistance, flexibility and formability.
6101 aluminum sheets can be hot-worked and cold-worked.
6101 alloy has a variety of tempering conditions, different tempering provides different strength, formability and conductivity level.
Welding of all standard processes can be completed, including gas torch welding, inert gas arc welding.

The Application of 6101 Aluminum Sheet Plate

6101 aluminum plate is often used in high-strength aluminum materials for buses, electrical conductors and heat dissipation equipment, bus conductors, etc.
