6001 aluminum tread checkered sheet
6001 aluminum tread checkered sheet
6001 aluminum tread checkered plate
6001 aluminum tread checkered plate
6001 aluminum tread checkered sheet
6001 aluminum tread checkered sheet
6001 aluminum tread checkered plate
6001 aluminum tread checkered plate

6061 Aluminum Tread Checkered Plate Sheet

  • Alloy:1060,1100,3003,3105,5005,5052,5251,5154,5454, 5754,5083,5086,6061,6082
  • Temper:O,H12,H14,H16,H18,H22,H24,H26,H32,H34, H36,H38,H111,H112,H114,H224,T4,T6
  • Width(mm):100-1850
  • Thickness(mm): 0.8-8.0
  • Length(mm): 500-16000

The Introduction of 6061 Aluminum Tread Checkered Plate Sheet

6061 aluminum tread checkered plate sheet has the advantages of novel shape, long service life and good anti-slip effect. It is mainly used in anti-slip flooring, decoration and other fields such as construction, vehicles and ships. Our company can produce pointer pattern plate, one rib pattern plate, two rib pattern plate, three rib pattern plate, five rib pattern plate and so on.Click to Order

6061 T6 aluminum pedals have the highest corrosion resistance of all heat treated aluminum. It is an alloy formed from silicon and magnesium. It is less strong than other comparable aluminums, but is still widely used. This is partly due to its corrosion resistance and partly due to its excellent mechanical properties. There are a variety of ways you can form 6061 aluminums, such as through machining and welding. The machinability rating of this alloy is 90 percent. It also has great joining capabilities. If needed, this product can be anodized or have other coatings.

  • 6001 aluminum tread checkered plate

The Product Specification of 6061 Aluminum Tread Checkered Plate Sheet

Alloy 1 Series 1060,1100
3 Series 3003,3105
5 Series 5005,5052,5251,5154,5454,5754,5083,5086
6 Series 6061,6063,6082
Temper O, H12, H14, H16, H18, H22, H24, H26,
 H32, H34, H36, H38, H111, H112, H114, H224, T4, T6
Thickness(mm) 0.8-8.0
Width(mm) 100-1850
Length(mm) 500-16000
Surface Bright finish, Mill finish
Bar difference 1 bar (Diamond/Pointer), 2 bar, 3 bar, big/small 5 bar
Weight about 2.5 tons per pallet
Standard product EN-1386,ASTM,GBT,JIS
Protection Paper interlayer



Available Dimension
Mill finish Surface Bright finish Surface
Thickness  (mm) 1.00---6.50mm 1.20---6.50mm
Pattern height Sheet Thickness from 1.0mm to 2.0mm,  bar height: 0.50mm Sheet Thickness from 1.0mm to 2.0mm,  bar height: 0.50mm
Sheet Thickness from 1.0mm to 2.0mm,  bar height: 1.00mm Sheet Thickness from 1.0mm to 2.0mm,  bar height: 1.00mm
Sheet Thickness above 2.0mm,  bar height: 1.50mm Sheet Thickness above 2.0mm,  bar height: 1.50mm
Width (mm) Maximum 1500mm Maximum 1650mm
Length (mm) max 6000mm for sheet or as require d for coil max 6000mm for sheet or as required for coil
Paper interleaves On request for selected On request for selected
Normal size 1200×2400mm, 1219×2438mm,  1219×3048mm 1200×2400mm, 1219×2438mm,  1219×3048mm

The Product Features of 6061 Aluminum Tread Checkered Plate Sheet

  • The 6061 aluminum tread checkered plate sheet has high hardness, good corrosion resistance, durability, and good anti-skid effect.
  • The 6061 aluminum tread checkered plate sheet is dense and defect-free and easy to polish and color.
  • The surface quality of the 6061 aluminum tread checkered plate sheet is good, without oil spots, waves, scratches, roll marks, and the trimming is neat and burr-free.
  • 6061 aluminum plate products of different thicknesses and shapes can be customized according to customer needs.

The Application of 6061 Aluminum Tread Checkered Plate Sheet

6061 aluminum tread checkered plate sheet is mainly used in anti-slip flooring, decoration and other fields of construction, vehicles, ships and so on. Such as base plates, truck components, marine fittings, marine components, marine hardware, electrical connectors, electrical fittings and camera lens mounts. This is only a few of the wide array of applications this alloy is used for. It also has the capability to be used for heavy duty structures that need corrosion resistance and good weight-to-strength ratio.
