5086 Aluminum Sheet Plate

  • Alloy: 5086
  • Temper: O,H111,H112,H116,H321
  • Width(mm): 100-2650
  • Thickness(mm): 0.15-600
  • Length(mm): 500-16000



5086 Aluminum Sheet Plate

The Introduction of 5086 Aluminum Sheet Plate

5086 aluminum plate belongs to the AL-Mg series alloy, magnesium content between 3.5% and 4.5%, is a kind of anti-rust aluminum and non-heat-treatable alloy with high corrosion resistance, good weldability and medium strength. 5086 Aluminum plate is higher strength than 5052, and better corrosion resistance than 5083, and its mechanical properties change significantly with hardening and temperature. It is not strengthened by heat treatment, but becomes stronger by strain hardening or cold working of the material. 5083 Alloy is easily welded and retains most of its mechanical strength. 5086 Aluminum plate has good welding results and good seawater corrosion properties, is a marine important aluminum alloy product in the fields of ships and offshore equipment.

5086 aluminum plate is widely used in occasions that require high corrosion resistance, good weldability and medium strength, such as ships, tank trucks and automobiles; pressure vessels, refrigeration devices, televisions towers, loading and exploration equipment, transportation equipment, etc. Flait Aluminum can produce 5086 aluminum plate, 5086 medium-thick aluminum plate, 5086 marine aluminum plate, 5086 ultra-wide aluminum plate, etc., and produce according to customized specifications.Click to Order

  • 5086 aluminium plate
  • 5086 aluminium plate
  • 5086 aluminium plate
  • 5086 aluminum plate

The Product Specification of 5086 Aluminum Sheet Plate

Alloy 5086 aluminum sheet plate
Temper O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38,H111,H112,H114,H116,H321,etc.
Thickness(mm) 0.15-600
Width(mm) 100-2650
Length(mm) 500-16000
Surface treatment Rolled, patterned aluminum plate
Package Export packaging (protective film, interleaved paper)
Certificate CCS, DNV, ABS, BV
Application Automobiles, ships, oxidizing materials, fuel tank materials, door panels, etc.



Chemical Composition:

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Ni

Zn

Ti

Zr

Al

5086

0.40

0.50

0.10

0.20-0.70

3.50-4.50

0.05-0.25

 -

0.25

0.15

 -

Remainder



Mechanical Properties:

Alloy

Temper

Tensile strength Rm(Mpa)

Yield strength Rp0.2(MPa)

Elongation A(%)

Hardness

5086

O/H111

204-305

95

16

65

H112

250

125

8

65-69

H116/H321

275

195

10

81

H32

275-335

185

5-10

80

H24/H34

300-360

220

4-8

88

H26-H36

325-385

250

3

96

The Product Features of 5086 Aluminum Sheet Plate

  • 5086 Aluminum plate has low density, light weight, high tensile strength, high elongation, and good corrosion resistance. 5086 aluminum plate has good anti-corrosion ability to air, water (or salt water), petrochemical and so on. Also, it has strong corrosion resistance in extremely industrial, marine atmospheric environments and deep water.
  • 5086 Aluminum plate has medium strength and has good weldability.
  • 5086 aluminum sheet has no low temperature brittleness, which is suitable for low temperature equipment. Even below 0°C, the strength and plasticity of 5086 aluminum plate will not change with the increase or decrease of temperature.
  • Its elastic modulus is small, which can absorb large impact stress.
  • 5086 Aluminum plate has high recycling value.
  • The surface of 5086 aluminum plate has no oil spots, no waves, no scratches, no roll marks, neat trimming, and no burrs.

The Application of 5086 Aluminum Sheet Plate

5086 aluminum plate is generally used in applications that require high corrosion resistance, good weldability, and moderate strength. For example, weldable parts of ships (ship sides, bottoms, outboards, decks, etc.) and automobiles; it can also be used in pressure vessels, refrigeration equipment, TV towers, transportation equipment, etc. that require strict fire protection.



5086 Aluminum Plate Packaging

1. Interleave paper or cover protective film on the aluminum plate to ensure that the surface of the aluminum plate is perfect without scratches;

2. Wrap it with plastic or kraft paper to prevent moisture and rain, and ensure that the aluminum plate is clean and free of dirt during transportation (each package has a moisture-proof desiccant);

3. Use wooden pallets with fumigation marks and reinforce them with steel belts to avoid collisions during transportation and ensure that the shape of the aluminum plate remains unchanged;

4. Pack according to customers’ requirements.
