1070 Aluminum Foil

  • Alloy: 1070
  • Temper: F,O,H18,H22,H24
  • Width(mm): 100-1600
  • Thickness(mm): 0.015-0.20
  • Length(mm): C

The Introduction of 1070 Aluminum Foil

1070 Aluminum foil is pure aluminum, the aluminum content is more than 99.7%. It is an aluminum foil material with good heat dissipation, electrical conductivity and thermal conductivity. It is suitable for making gaskets and capacitors from aluminum foil, especially in electronic components because of its good conductivity. Electronic components are components of electronic components and small electrical machines and instruments. They are composed of several parts, among which electronic aluminum foil will be used. Electronic aluminum foil is a kind of aluminum foil processed by a series of rolling, cleaning and cutting processes on high-purity aluminum ingots. It is the raw material for the production of electrode foil. The main products of electronic aluminum foil are 1070 aluminum foil, 1100A aluminum foil and 3003 aluminum foil.Click to Order

  • 1070 aluminum foil
  • 1070 aluminum foil
  • 1070 aluminum foil
  • 1070 aluminum foil

The Product Specification of 1070 Aluminum Foil

Alloy 1070 aluminum foil
Temper F,O,H14,H16,H18,H19,H22,H24,H26,H28,etc.
Thickness (mm) 0.015-0.20
Width (mm) 100-1600
Length (mm) C
Conductivity (% IACS) 1070 O ≥ 62.7% IACS
Surface Mill finish
ID 76mm,152mm,408mm,508mm or customized
Standard ASTM-B-209M,BS EN 485-2,BS EN 573-3,GB/T3880-2008
Certificate Mill Test Certificate, Certificate of origin: Form A, Form E, CO
Package Export standard, Eye to sky or eye to wall
Application Transformers, electronic components, food packaging.



Chemical composition:

Alloy Al (%) Si (%) Fe (%) Cu (%) Mn (%) Zn (%) Mg (%) Ti (%) V
1070 99.7 0.0431 0.203 0.0022 0.0104 0.0093 0.0013 0.02 0.0039

The Product Features of 1070 Aluminum Foil

  • 1070 Aluminum foil has high purity and good electrical and thermal conductivity.
  • 1070 Aluminum foil has strong plasticity and good corrosion resistance.
  • The surface of 1070 aluminum foil has no black oil spots, scratches, bright lines, roll marks and other defects.

The Application of 1070 Aluminum Foil

1070 Aluminum foil is widely used in transformers, aluminum gaskets, electrolytic capacitors, cosmetic lid and so on.
