6005 Aluminum Sheet Plate

  • Alloy: 6005
  • Temper: F,O, T4,T6,T651,H112
  • Width(mm): 500-2650
  • Thickness(mm): 0.30-600
  • Length(mm): 500-16000

The Introduction of 6005 Aluminum Sheet Plate

6005 Aluminum sheet plate belongs to Al-Mg-Si alloy, which has medium strength, good plasticity, corrosion resistance, weldability and formability, and excellent comprehensive performance. 6005 Aluminum plate is a kind of anti-rust aluminum widely used. This alloy has a wide range of applications, especially in the construction industry. It is a promising alloy, cannot be strengthened by heat treatment and can be polished.

6005 Aluminum plate has similar properties to 6106 and 6082 aluminum alloys and is sometimes used interchangeably with them, but 6005/6005A has better extrudability. However, 6005 and 6005A have different chemical compositions and should not be confused. 6005 aluminum sheet contains a large amount of silicon, which lowers the melting temperature and improves its extrudability. 6005 Aluminum plate is similar to 6061 aluminum alloy. 6005-T5 temper has the same minimum tensile strength and yield strength as 6061-T6, and has better machinability and strength properties than 6063-T6 aluminum sheet. 6005A Aluminum alloy may also replace 6061 because of its better extrudability and surface appearance.Click to Order

  • 6005 aluminum sheet
  • 6005 aluminum sheet
  • 6005 aluminum plate
  • 6005 aluminum plate

The Product Specification of 6005 Aluminum Sheet Plate

Alloy 6005 aluminum sheet plate
Temper F,O, T4,T6,T651,H112,etc.
Thickness
(mm)
0.30-600
Width
(mm)
500-2650
Length
(mm)
500-16000
Application Oil tanks, gasoline or lubricating oil conduits, various liquid containers and other small load parts made by deep drawing, etc.



Chemical composition:

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Zn

Ti

Others

Al

6005

0.6-0.9

0.35

0.1

0.1

0.4-0.6

0.1

0.1

0.15

97.5-99.0

The Product Features of 6005 Aluminum Sheet Plate

  • 6005 aluminum plate has high strength, good plasticity, corrosion resistance, weldability, formability and better extrusion properties.
  • The welding performance of 6005 aluminum plate is similar to 5182 aluminum sheet, can use gas welding, argon arc welding, spot welding and roll welding.
  • 6005 Aluminum alloy cannot be strengthened by heat treatment. The plasticity is good during semi-cold work hardening, the plasticity is low when cold work hardening, the machinability is poor, and it can be polished, good cold workability.
  • The surface of 6005 aluminum plate has no oil spots, no waves, no scratches, no roll marks, neat trimming, and no burrs.

The Application of 6005 Aluminum Sheet Plate

6005 aluminum plate is mainly used in the manufacture of welded structural parts, mechanical parts with high plasticity and high corrosion resistance, high-speed trains, subways, urban light rail and other rail transit vehicle bodies, building curtain walls, gates, etc.
