7020 Aluminum Sheet Plate

  • Alloy: 7020
  • Temper: F,O,T6,T651,T7451,H112
  • Width(mm): 800-2500
  • Thickness(mm): 1.00-600
  • Length(mm): 900-10000



7020 Aluminum Sheet Plate

The Introduction of 7020 Aluminum Sheet Plate

7020 aluminum plate belongs to medium and high strength Al-Zn-Mg alloy, which has high strength, good welding performance and process performance. It is the main welding structural material for aerospace, ground vehicles and equipment, and is widely used in the manufacture of high-speed train vehicles body. 7020 aluminum plate has good comprehensive properties after heat treatment. The strength of 7020 aluminum plate is greater than that of 6082, but its forming ability is correspondingly worse. 7020 aluminum sheet has high tensile strength, high yield strength and good corrosion resistance; 7020 aluminum alloy can be processed and formed in various ways such as hot rolling, extrusion, cold working; 7020 aluminum plate has good welding performance, can use a variety of welding methods. The hardness state of 7020 aluminum alloy after heat treatment is usually T6 temper. T6 state refers to the hardness state of aluminum alloy after artificial age hardening treatment, which has good strength and hardness. The hardness of 7020 aluminum alloy is slightly higher than ordinary aluminum alloy, about 160~170HB.Click to Order

  • 7020 aluminum sheet
  • 7020 aluminum sheet
  • 7020 aluminum plate
  • 7020 aluminum plate

The Product Specification of 7020 Aluminum Sheet Plate

Alloy 7020 aluminum sheet plate
Temper F、O、T6、T651、T7451、H112,etc.
Thickness
(mm)
1.0-600
Width
(mm)
800-2500
Length
(mm)
900-10000
Application Aviation, airplane, aero, etc.



Chemical composition:

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Zn

Zr

Zr+Ti

Others

AL

7020

0.35

0.40

0.20

0.05-0.50

1.0-1.4

0.10-0.35

4.0-5.0

0.08~0.20

0.08-0.25

Single

Total

Balance

0.05

0.15



Mechanical properties:

Alloy & Temper

Tensile strength

Rm/Mpa

Yield strength

Rp0.2/Mpa

Elongation

%

Hardness

HB/Wα

7020-T651

330

260

7

-

The Product Features of 7020 Aluminum Sheet Plate

  • High strength, good welding performance and process performance;
  • High tensile strength, high yield strength and good corrosion resistance;
  • The process performance of 7020 aluminum plate is good.

The Application of 7020 Aluminum Sheet Plate

7020 Aluminum plate is used in airplane, high-speed rail frames, armoured vehicles, military bridges, motor cycle and bicycle frames.
