1100 Aluminum Foil

The Introduction of 1100 Aluminum Foil

1100 Aluminum foil is pure aluminum, the aluminum content is more than 99%. 1100 Alloy compared to 1060 and 1070 aluminum foil, the content of (Fe + Si) in 1100 aluminum foil is higher than 1060 and 1070, and the content of Fe can improve the strength and toughness of aluminum foil. 1100 aluminum foil has good formability, corrosion resistance, thermal conductivity and certain strength. It is widely used in heat exchangers, air-conditioning foils in the refrigeration industry, storage in the chemical and food industries containers, capacitor casing materials in the electronics industry, etc.Click to Order

The Product Specification of 1100 Aluminum Foil

Alloy	1100 aluminum foil
Temper	F,O,H14,H16,H18,H19,H22,H24,H26,H28,etc.
Thickness(mm)	0.015-0.2
Width(mm)	100-1600
Length (mm)	C
Surface	Mill finish
ID	76mm,152mm,408mm,508mm or customized
Standard	ASTM-B-209M,BS EN 485-2,BS EN 573-3,GB/T3880-2008
Certificate	Mill Test Certificate, Certificate of origin: Form A, Form E, CO
Package	Export standard, Eye to sky or eye to wall
Application	Electronic components, food packaging.

Chemical Composition of 1100 aluminium foil
Alloy	Si+Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others		Al
								Individual	Total
1100	0.95	0.05-0.2	0.05	-	-	0.1	-	0.05	0.15	99.0

Mechanical propertiesof 1100 aluminium foil
Alloy	Temper	Thickness(mm)	Tensile Strength（Mpa）	Yield Strength（Mpa）	Elongation(%)	Cupping test value I.E/mm
1100	O	0.08-0.10	80-110	≥50	≥18	≥6.0
	O	0.10-0.20	80-110	≥50	≥20	≥6.5
	H22	0.08-0.10	100-130	≥60	≥18	≥5.5
	H22	0.10-0.20	100-130	≥60	≥20	≥6.0
	H24	0.08-0.10	115-145	≥70	≥15	≥5.0
	H24	0.10-0.20	115-145	≥70	≥18	≥5.5
	H26	0.08-0.10	130-160	≥90	≥8	≥4.0
	H26	0.10-0.20	130-160	≥90	≥10	≥4.5
	H18	0.08-0.20	≥160	-	≥1	-

The Product Features of 1100 Aluminum Foil

1100 Aluminum foil has high plasticity, good electrical and thermal conductivity.
1100 Aluminum foil has high purity, clean degreasing, less holes, and good product shape.
The surface of 1100 aluminum foil has no black oil spots, scratches, bright lines, roll marks and other defects.

The Application of 1100 Aluminum Foil

1100 Aluminum foil is widely used in food packaging, aluminum foil gaskets, electrolytic capacitors, electronic components, etc.

Related Products

1060 Aluminum Foil

The aluminum content of 1060 aluminum foil is as high as 99.6%, which belongs to the widely used industrial pure aluminum foil.

3003 Aluminum Foil

3003 aluminum foil is a commonly used product of AL-Mn series alloys. This product has good antirust properties, and its strength is about 10% higher than that of 1100 aluminum foil and 1060 aluminum foil. It has good formability, weldability and corrosion resistance. For processing parts that require good formability, high corrosion resistance and good weldability.

8011 Aluminum Foil

8011 aluminum foil has mature production technology, stable quality, and excellent mechanical properties such as elongation and tensile strength. It is used in the production of various single and double zero foils, bottle cap punching materials, air conditioner foil radiator fin materials, In the fields of architectural decoration and other fields, it is a product with a wide range of uses and a large amount of aluminum foil.

The aluminum content of 1100 aluminum foil is more than 99%. 1100 aluminum foil has good formability, corrosion resistance, thermal conductivity and certain strength. It is widely used in heat exchangers, air-conditioning foils in the refrigeration industry, storage in the chemical and food industries Containers, capacitor casing materials in the electronics industry, etc.
