3004 Aluminum Coil - Flait Aluminum

The Introduction of 3004 Aluminum Coil

3004 Aluminum coil is an AL-Mn alloy, and it is also a widely used anti-rust aluminum. 3004 Aluminum coil has good formability, weldability and corrosion resistance. For processing parts that require good formability, high corrosion resistance and good weldability. The requirements of 3004 aluminum coil and 3003 aluminum coil alloy are basically the same in all aspects. However, the strength of 3004 aluminum coil is also higher than that of 3003 aluminum coil, which is relatively good in terms of corrosion resistance and product formability. 3004 Aluminum coil belongs to the Al-Mnx series alloy, which has high formability, solubility, corrosion resistance, good processing formability and excellent performance in corrosion-resistant devices. 3004 Aluminum coil is commonly used in the production of all-aluminum pop cans, mainly used in food production and storage and transportation containers, such as tableware, trays, cake trays, etc.Click to Order

The Product Specification of 3004 Aluminum Coil

Alloy	3004 aluminum coil strip
Temper	F,O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H112,H114,etc.
Thickness (mm)	0.2-10
Width (mm)	100-2650
Length (mm)	C
ID	Ø505mm or customized
Package	Eye to sky or Eye to wall
Application	Tableware, trays, cake trays, etc.

Chemical composition:

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Zr	Others		AL
3004	0.30	0.70	0.25	1.00-1.50	0.80-1.30	-	0.25	-	-	Single	Total	Balance
										0.05	0.15

Mechanical properties:

Alloy & Temper

Tensile strength

Rm/Mpa

Yield strength

Rp0.2/Mpa

Elongation

Hardness

HBWα

3004-H24

150-285

110

The Product Features of 3004 Aluminum Coil

3004 Aluminum coil has good formability and good processing characteristics.
3004 Aluminum coil has high corrosion resistance and good weldability.
3004 Aluminum coil has good deep drawability and high plasticity.

The Application of 3004 Aluminum Coil

3004 Aluminum coils are mainly used in chemical product production and storage devices, thin plate processing parts, building materials, building baffles, cable ducts, sewers, various lighting parts, beverage cans, corrugated boards, building materials, color-coated aluminum coils, lamp holders, shutters.e appliances, etc. The fields that do not require high product strength.
