  • Alloy:5052,5083,6061,7075
  • Temper:H111,H112,H116,H321,T6,T651
  • Thickness(mm):3-40
  • Maximum width(mm):2500
  • Maximum length(mm):6200

The Introduction of High-Precision Ultra-flat aluminum plate

High-precision ultra-flat aluminum plate is an aluminum plate material with high precision and ultra-flat surface. The surface of this type of aluminum plate is polished to more than 400 mesh, without milling, and can be anodized directly. It has extremely small thickness tolerance and high flatness, which can reduce processing deviation and error. At the same time, high-precision ultra-flat aluminum plate has excellent mechanical properties, good strength and corrosion resistance, and is suitable for various processes, such as cutting, punching, bending and Welding etc. Flait Aluminum provides 5052 5083 6061 7075 high-precision ultra-flat aluminum plates.Click to Order

  • High-Precision Ultra-flat aluminum plate
  • High-Precision Ultra-flat aluminum plate
  • High-Precision Ultra-flat aluminum plate
  • High-Precision Ultra-flat aluminum plate

The Product Specification of High-Precision Ultra-flat aluminum plate

Alloy

Quality Level

Thickness

(mm)

Tolerance of Thickness

(mm)

Flatness

(mm/m²)

HB

Regular size

5052/5083

A+

4-20

±0.1

0.1

55-65

1525*3050/1500*3000

25-40

-0.1-0.2

0.2

55-65

1525*3050/1500*3000

A

4-20

±0.05

0.1

55-65

1525*3050/1500*3000

6061 T651

A+

3-12

±0.05

0.1

90-110

2000/2500*5000/6200

15-20

±0.05

0.1

90-110

1525*5000

25-40

±0.1

0.1

90-110

1250*5000

A

3-12

±0.1

0.1

90-110

2000/2500*5000/6200

15-20

±0.1

0.2

90-110

1525*5000

25-40

-0.1-0.2

0.2

90-110

1250*5000

7075 T651

A

3-12

±0.1

0.1-0.5

>150

1250*2500/5000

15

±0.2

0.2-0.5

>150

1250*2500/5000

The Product Features of High-Precision Ultra-flat aluminum plate

5052/5083 high-precision ultra-flat aluminum plate:

1.Good corrosion resistance, easy to process and weld.

2.The surface is polished with more than 400 meshes, no milling surface, and can be directly anodized.

3.Thickness tolerance can reach±0.05mm, flatness 0.1mm/m2.

4.Using special technology to eliminate stress.



6061 T651 high-precision ultra-flat aluminum plate:

1.It has excellent corrosion resistance and can effectively resist the erosion of oxidative, acidic and alkaline environments

2.The surface is polished with more than 400 meshes, no milling surface, and can be directly anodized.

3.Thickness tolerance can reach±0.05mm, flatness 0.1mm/m2.

4.Using special technology to eliminate stress.

5.Greatly reducing the deformation.



7075 T651 high-precision ultra-flat aluminum plate:

1.7075 aluminum alloy has very high tensile strength and yield strength, as well as excellent fatigue resistance.

2.The surface is polished with more than 400 meshes, no milling surface, and can be directly anodized.

3.Thickness tolerance can reach±0.1mm, flatness 0.1-0.5mm/m2.

4.The product has high hardness and strong bending resistance.

The Application of High-Precision Ultra-flat aluminum plate

  • 5052/5083 high-precision ultra-flat aluminum plate is mainly used for electronic and electrical product accessories, medical equipment, optical instruments, high-precision tooling, fixtures, carriers, etc.
  • 6061 T651 high-precision ultra-flat aluminum plate is often used in pipes and welding parts, automation equipment, tooling fixtures (no deformation after high temperature furnace), building and construction products, precision parts, auto parts, various molds, etc.
  • 7075 T651 high-precision ultra-flat aluminum plate is used in aerospace, military supplies, ultrasonic plastic welding abrasives, SMT furnace fixtures, carriers, precision parts, etc.
