2014 Aluminum Sheet Plate

Alloy: 2014
Temper: F,O,H112,T3,T4,T6,T351,T651
Width(mm): 500-2650
Thickness(mm): 1.00-600
Length(mm): 500-16000

Quick Quote Get A Quote

The Introduction of 2014 Aluminum Sheet Plate

2014 Aluminum sheet plate is an Al-Cu-Mg-Si series high-strength wrought aluminum alloy, the copper content between 3.9% and 5.0%, can be strengthened by heat treatment. The chemical composition of 2014 alloy is similar to 2A14 aluminum alloy, it has high strength and good hot workability, and is easy to forge. The performance is basically the same as 2A14. Due to the high copper content of 2014 aluminum sheet, the strength is high, corrosion resistance is poor, and it is prone to intergranular corrosion and stress corrosion, the aluminum plate can be clad with pure aluminum to enhance its corrosion resistance. Its weldability and cutting performance are still good.Click to Order

The Product Specification of 2014 Aluminum Sheet Plate

Alloy	2014 aluminum sheet plate
Temper	F, O, H112, T3, T4, T42, T62, T6, T351, T651, etc.
Thickness (mm)	1.0-600
Width (mm)	500-2650
Length (mm)	500-16000
Application	Automobile molds, aluminum molds, precision molds, shoe molds, high-strength parts, heavy forgings, etc.

Chemical composition:

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Zr	Others		AL
2014	0.50-1.20	0.70	3.90-5.00	0.40-1.20	0.20-0.80	0.10	0.25	0.15	-	Single	Total	Balance
										0.05	0.15

Mechanical properties:

Alloy & Temper

Tensile strength

Rm/Mpa

Yield strength

Rp0.2/Mpa

Elongation

Hardness

HBWα

2014-T4

440

280

120

2014-T6

≥440

≥390

≥6

111

The Product Features of 2014 Aluminum Sheet Plate

2014 aluminum sheet plate has super high strength and good cutting processing performance, and can adapt to high temperature environment.
2014 aluminum sheet plate has low density, high specific modulus, good thermal conductivity, electrical conductivity, and good manufacturing process performance.
Flait Aluminum has the production line to produce ultra-wide and ultra-thick aluminum plate, our 2014 aluminum plate has good mechanical properties, high strength, easy processing, and good performance.

The Application of 2014 Aluminum Sheet Plate

2014 aluminum plate is used in occasions requiring high strength and hardness (including high temperature), such as: molds, high-strength machine parts, heavy forgings, thick plates and extruded materials, wheels, truck frames and suspension system parts, etc.
