Home > News & Blog > News > High precision ultra-flat 5052 aluminum plate manufacturer
High precision ultra-flat aluminum plate is a relatively high-end aluminum alloy plate. Flait Aluminum is a large aluminum alloy product manufacturer that produces and supplies aluminum plates and foils of various specifications. Among them, high-precision ultra-flat 5052 aluminum plate is one of Flait Aluminum’s star products. 5052 high-precision ultra-flat aluminum plate has both excellent plate thickness accuracy and surface flatness. While meeting customers’ needs for reducing residual stress and improving surface quality, it also saves customers costs and is very suitable for precision machining.
| Alloy Name | high precision ultra-flat 5052 aluminum plate |
| Temper | H111,H112 |
| Thickness(mm) | 4-50 |
| Regular size(mm) | 1250*2500/1500*3000/1525*3050 |
| Flatness(mm/m²) | 0.1-0.2 |
| HB | 55-65 |
| Applications | Semiconductor manufacturing equipment, LCD manufacturing equipment, Solar panel manufacturing equipment, Robots, Medical equipment, OA equipment, Optical equipment, Various molds, Tools, etc. |
| Thickness(mm) | Tolerance of Thickness (mm) | Deviation per original plate (reference) |
| 4≤t≤6 | ±0.04 | 0.02 |
| 6<t≤12 | ±0.05 | 0.03 |
| 12<t≤16 | ±0.08 | 0.05 |
| 16<t≤18 | ±0.09 | 0.06 |
| 18<t≤22 | ±0.10 | 0.07 |
| 22<t≤25 | ±0.12 | 0.09 |
| 25<t≤35 | ±0.15 | 0.12 |
| 35<t≤45 | ±0.20 | 0.15 |
| 45<t≤50 | ±0.25 | 0.2 |
| Thickness (mm) | Tensile Strength (N/mm2) | Yield Strength (N/mm2) | Elongation (%) |
| 4≤t≤13 | 226 | 133 | 23 |
| 13<t≤50 | 203 | 104 | 31 |
Good corrosion resistance, easy to process and weld.The surface is polished with more than 400 meshes, no milling surface, and can be directly anodized.Thickness tolerance can reach±0.05mm, flatness 0.1mm/m2.Using special technology to eliminate stress.1.Advanced production equipment
Flait has multiple semi-automatic/automatic precision cutting equipment. The cutting plate thickness range is 4mm~100mm, and the maximum plate size is 2200*6000mm. The cutting deformation is very small and the yield is high.
2.High quality aluminum
We adopt high standards of raw material selection and strict quality control measures, use advanced processing techniques and equipment to produce the high quality aluminum materials, occupy the market with quality and improve customer satisfaction.
3.Customizable
We provide high precision ultra-flat 5052 aluminum plate with a variety of sizes and specifications to meet the different needs of your project.
4.Competitive price
A powerful supply chain system provides efficient and economical solutions and quick quotations.
5.Reliable and timely delivery
We know time is very important for your project, we guarantee timely delivery, check carefully and provide inspection report before shipment.
6.Experienced team
With years of industry experience, Flait Aluminum has explored and accumulated rich knowledge of the needs of aluminum raw material suppliers in various fields, can quickly and accurately understand the different needs of different customers, provide reliable technical support and high-quality aluminum products.
Original Source:https://www.flait-aluminum.com/High-Precision-Ultra-flat-aluminum-plate.html
Tags:High precision ultra-flat aluminum plate,5052 aluminum plate
