What are 1060 & 3003 aluminum roll jacketing?

2023-12-04 17:44:41

aluminum roll jacketing

Aluminum roll jacketing is a commonly used insulation material. It is often used for pipe insulation, tank insulation, refrigerators, air conditioners and other fields. Aluminum roll jacketing is very popular because of its cheap price, strong corrosion resistance, light weight and easy cutting. Flait Aluminum can produce 1060 aluminum roll jacketing (pure aluminum serie), 3003 aluminum roll jacketing (anti-rust aluminum serie), 5052 aluminum roll jacketing (corrosion-resistant aluminum serie) and so on. Thermal insulation aluminum coils have beautiful appearance, smooth appearance, can be well adapted to pipe insulation packaging, and be used for about 20 years in the natural environment.

1060 aluminum roll jacketing and 3003 aluminum roll jacketing are the most commonly used pipe insulation materials. 1060 aluminum roll jacketing is a pure aluminum coil, which is suitable for projects with low requirements and does not contain corrosive liquids, the price is economical and affordable; 3003 aluminum roll jacketing contains 1.0-1.5% manganese alloy, which has better corrosion resistance and is often used in some corrosive gas/liquid pipes. Thickness of 0.4mm and 0.5mm aluminum roll jacketing are the main products of our company. Aluminum jacketing rolls have good thermal insulation effect and long service life. They are made of high-quality aluminum ingots. Other commonly used thicknesses are 0.6 and 0.8mm. Normal pipe insulation aluminum jacketing should not be too thick, which will make it difficult to operate, nor too thin, which will not play the role of insulation. The commonly used thickness is about 0.5mm and the width is 1m. In addition, our company can cut it into different sizes (15m, 30m, 60m, 90m, etc.) according to customer requirements to facilitate direct construction and use.Click to Order

Advantages of 1060 & 3003 aluminum roll jacketing

1.Corrosion-resistant, rust-proof and waterproof

Aluminum roll jacketing has good corrosion resistance. Compared with iron sheet, the thermal insulation aluminum jacketing has a longer service life. It is not easy to corrode and age when used in outdoor environments. It has a beautiful surface. Therefore, many power and chemical companies now use aluminum roll jacketing as insulation material.

2.Fire and heat insulation

The aluminum roll jacketing will not melt after high temperature. When the insulating aluminum jacketing encounters fire or high temperature, it has a very good thermal insulation function. Its surface heats up quickly and produces char to resist the spread of flames and protect the inner core. It has good fire resistance and heat insulation properties.

3.Light weight and low cost

The density of the aluminum is low, so the mass of the aluminum roll jacketing is lighter for the same area, the recycling value is high; the aluminum roll jacketing insulation is not easily corroded and has a long service life, usually more than 20 years, and will not change color, the gloss is very good.

4.Beautiful surface and easy to process

The appearance of the aluminum roll jacketing is smooth and beautiful, so you don’t have to worry about the product becoming rusty in the future. Aluminum has relatively high plasticity and can be easily bent and wound, effectively improving work efficiency.

Alloy 1060 aluminum roll jacketing & 3003 aluminum roll jacketing
Temper H14, H16, H24, H26
Thickness 0.3-1.5mm
Width 914mm, 1000mm, 1200mm, 1219mm, etc.
Length 50′ (15 meters), 100′ (30 meters), 200′ (60 meters), 300′ (90 meters), Coil (specify lengths), Flat Sheets (cut to length), Cut & Rolled (to specific lengths)
Inner diameter 75mm, 150mm, 305mm, 405mm, 505mm with or
without aluminum/paper core
Surface treatment Mill finish, smooth/plain, stucco embossed, corrugated
Moisture barrier Polysurlyn, composite kraft paper
Surface lamination Kraft paper laminated
Kraft paper thickness About 0.1mm
Polysurlyn thickness About 0.076mm (3mil)
Quality standard ASTM B209,ISO9001, GB/T3880
Quantity Have ready stock for most common thickness roll small quantity order are acceptable.
Package Eye to sky / Eye to wall; 2.5 tons/per coil; we can cut aluminum jacketing coil into small rolls required by the customer; export standards.
Sample Free


Weight calculation of 1060 & 3003 aluminum roll jacketing

The density of 1060 aluminum roll jacketing is 2.71, 3003 aluminum roll jacketing is 2.73, and the weight calculation formula of aluminum roll jacketing is: thickness (mm) * density * width (m) * length (m) = weight (kg)

How to identify the advantages and disadvantages of 1060 & 3003 aluminum roll jacketing

When the master workers are doing cutting and insulation construction, they always hope that the aluminum roll jacketing will be smoother and easier to use. Only in this way can the pipes and tanks wrapped out be beautiful. When the aluminum roll jacketing is uneven, especially when the wrapping area is relatively large, it will produce uneven effects, thus affecting the appearance. Therefore, the smooth aluminum roll jacketing is better. In order to make the coil quality meet the requirements during production, the rolling processing is important. Our company strictly implements the rolling process to ensure the smoothness and flatness of the coil.

Excellent aluminum roll jacketing needs to have a smooth surface without oil stains, color differences, oxidation spots and other problems. At the same time, the aluminum roll jacketing must be suitable for wrapping around pipes, be able to hold the edge well, have uniform thickness. The tolerance must be controlled within 0.02mm. Only such products can become high-quality aluminum roll jacketing.
