5083 aluminum sheet plate for ships

2023-11-30 15:24:30

5083 aluminum plate is very suitable for ship construction due to its good corrosion resistance and can resist seawater erosion. 5083 marine aluminum plate has high corrosion resistance and good anti-rust function, which can resist corrosion. The hull is affected by sea water, marine climate and harsh environment. Reducing maintenance costs such as oil filling is of great significance to the safety and life of the ship. 5083 marine aluminum plates are mainly used for decks, engine bases, ship sides, outer bottom plates, keels and hull structural materials.

5083 H116 H321 aluminum plates are mainly used for ship decks, sides, bottom shells, engine bases and keels, etc. At the same time, it also needs to have corrosion resistance, wear resistance, high strength and hardness. 5083 H116 H321 aluminum plate has better corrosion resistance and is more suitable for marine underwater environments than H111 and H112 states.

5083 aluminum sheet plate for ships

Specification of 5083 Aluminum Plate for Ships

Alloy 5083
Temper O,H111,H112,H116,H24,H32,H321
Thickness (mm) 1.50-120
Width (mm) ≤3100
Length (mm) 1000-16000
Certificate DNVGL,ABS,LR,CCS
Surface treatment Anodizing, spraying or other surface treatment

Chemical Composition

Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Zr AL
5083 0.40 0.40 0.10 0.40-1.00 4.00-4.90 0.05-0.25 0.25 0.15 Remainder

Mechanical Properties

Alloy Temper Tensile strength Rm(Mpa) Yield strength Rp0.2(MPa) Elongation A(%)
5083 O/H111/H112 ≥275 ≥125 ≥16
H116 ≥305 ≥215 ≥10
H321 305-385 215-295 ≥12


Advantage of 5083 Aluminum Plate for Ships

  • Corrosion resistance: 5083 aluminum plate is a typical rust-proof aluminum plate and will not rust even under harsh conditions such as sea water. This reduces the vessel’s maintenance costs and increases its service life.
  • Lightweight: The use of 5083 aluminum plates can reduce the weight of the ship, increase the speed, and at the same time reduce fuel consumption and save fuel consumption. This is of great help in improving the navigation efficiency of ships and reducing operating costs.
  • Good mechanical properties: 5083 aluminum plate has excellent strength and rigidity and can meet the various needs of ships.
  • Easy to process: 5083 aluminum plates are easy to process in various forms such as cutting, stamping, cold bending, forming and cutting, and are suitable for streamlined hulls. This makes the ship manufacturing process more convenient.
  • High strength and fatigue resistance: 5083 aluminum plate has high strength and fatigue resistance, and can withstand various stresses in the marine environment, ensuring the safety and stability of the ship.
  • Good thermal insulation performance: 5083 aluminum plate has a low thermal conductivity and good thermal insulation performance, which can effectively reduce the temperature change of the ship and improve the comfort and safety of the ship.
  • Bulletproof and explosion-proof performance: 5083 aluminum plate has good bulletproof and explosion-proof properties, which can effectively protect the safety of ships and crews.
  • Beautiful and durable: The surface of 5083 aluminum plate is smooth and beautiful, not easy to rust, and can maintain the beauty and durability of the ship.


Application of 5083 Aluminum Plate for Ships

  1. During the construction of ships, 5083 aluminum plates can be used for external parts such as hulls, bottom plates, and side plates. These parts need to withstand a certain amount of pressure and weight, and also need to have corrosion resistance, wear resistance, strength and hardness. high.
  2. 5083 aluminum plates can also be used in the internal structures of ships, such as cargo holds, fuel tanks, etc. These parts need to withstand greater weight and pressure, and also need to have good sealing and corrosion resistance. 5083 aluminum plate can be stretched, bent, etc. to form the required shape and size.
