5083 O aluminum sheet for ships

2023-06-29 16:01:49

5083 O Aluminum sheet for ships has excellent corrosion resistance to seawater. This allows it to maintain its performance and appearance for long periods of time when used in ships and marine environments, extending the life of the ship. In ship design, the lower density of 5083 O aluminum sheets for ships can reduce the overall weight, improve the ship’s fuel efficiency, reduce operating costs, and increase the ship’s load-carrying capacity and stability.Click to Order

5083 O Aluminum sheet for marine use can be easily cut, formed, drilled and stamped. This makes operation and construction easier during ship building and repair.



Features of 5083 O Aluminum Sheet for Ships

  • Excellent Corrosion Resistance: 5083 O aluminum sheet has outstanding resistance to seawater and industrial chemicals, ideal applications.
  • High Strength: Despite being in the soft state, 5083 O aluminum sheet still exhibits relatively high strength, ensuring structural integrity for boat construction.
  • Weldability: This aluminum alloy is highly weldable, allowing for easy fabrication and joining different.
  • Lightweight: 5083 O aluminum sheet has a low density, contributing to lightweight boat construction, which can improve fuel efficiency and increase payload capacity.

Specification of 5083 O Aluminum Sheet for Ships

Alloy 5083
Temper O,H111,H112,H116,H24,H32,H321
Thickness (mm) 1.50-120
Width (mm) ≤3100
Length (mm) 1000-16000
Surface treatment Mill finish, but can also be coated or painted based
Tensile strength ≥275 MPa
Yield strength ≥125MPa
Elongation ≥16%
Hardness 45-60 HB
Certification ABS (American Bureau of Shipping), DNV (Det Norske Veritas) and other international standards.

Chemical Composition

Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Zr Al
5083 0.40 0.40 0.10 0.40-1.00 4.00-4.90 0.05-0.25 0.25 0.15 Remainder



Application of 5083 O Aluminum Sheet for Ships

  • 5083 O Marine aluminum plates are often used to manufacture hull plates, including hull shells and hull bulkheads. It has good corrosion resistance and high strength, and can resist seawater erosion and the stress of the hull structure.
  • 5083 O Marine aluminum sheets are also used to make ship decks. It has high weather resistance and anti-slip properties, providing safe and secure walkways and work areas.
  • 5083 O Aluminum sheets for ships can also be used for internal structures of ships, such as bulkheads, deck covers and compartment doors. It has lower density and higher strength, which reduces ship weight and increases load carrying capacity.
  • 5083 O Aluminum sheets for ships are also widely used in the manufacture of wind power generation equipment, such as wind power generation towers, wind turbine blades, etc. It can meet the requirements for lightweight, corrosion resistance and strength of wind power generation equipment.



Original Source: https://www.flait-aluminum.com/Marine-grade-aluminum-sheet.html

Tags: 5083 aluminum sheet , 5083 aluminum plate
